<div class="contents">
Replace the All-Metal Hotend

The replacement process for the M5 all-metal hotend is the same as for a standard PTFE hotend. You can refer to the following resources for more details:

<ul><li style="list-style-type: disc;">Video:<a href="https://support.ankermake.com/s/article/How-to-Replace-the-Hotend" style="text-decoration: none;" target="_blank"> How to Replace the Hotend</a></li><li style="list-style-type: disc;">Article:<a href="https://support.ankermake.com/s/article/How-to-Replace-the-Metal-Hotend-Component-for-the-M5-Printer" style="text-decoration: none;" target="_blank"> How to Replace the Metal Hotend Component for the M5 Printer</a></li></ul>


<h2 style="line-height: 1.7999999999999998;margin-top: 24px;margin-bottom: 5px;">Change the Hotend Type via the App</h2>

<h3 style="line-height: 1.7999999999999998;margin-top: 19px;margin-bottom: 5px;">Steps:</h3>

A. Ensure the App and Firmware are Updated:

<ul><li style="list-style-type: disc;">Make sure that the app is updated to version V1.3.1 or above.</li><li style="list-style-type: disc;">Ensure the printer&#39;s firmware is updated to version V3.0.70 or above.</li></ul>

B. Locate the Printer in the App:

<ul><li style="list-style-type: disc;">Find the printer with the all-metal hotend replacement in the app.</li><li style="list-style-type: disc;">Go to the Settings page</li><li style="list-style-type: disc;">Click on &#39;Accessories.&#39;</li><li style="list-style-type: disc;">Choose the all-metal hotend to complete the setup.</li></ul>


Warning:

<ul><li style="list-style-type: disc;">M5 will enable 300°C high-temperature printing when the all-metal hotend is chosen in the app.</li><li style="list-style-type: disc;">Do not enable this option if the M5 does not have the all-metal hotend replacement, as it may cause damage and be potentially dangerous.</li></ul>

<img height="399" src="https://lh7-us.googleusercontent.com/docsz/AD_4nXeRJOCfKQPn5YjmRiWmuyBG_9MFRvhKaPATR2kwuQtqcKbrHwcK8Ne5e0LIuQEk-QltuDteedsprIraAPxXL7qdPBPNjNfuP4aJ6lLBGTAxyXScD1rWBTD8pQtynw4qmXAac2fUpzUVnbl8pY0eeJ-frKg?key=CkkiGiwEiBRjhMUfKSOfFA" width="602"></img>

<h2 style="line-height: 1.7999999999999998;margin-top: 24px;margin-bottom: 5px;">Select the M5 All-Metal Hotend During Slicing</h2>

<h3 style="line-height: 1.7999999999999998;margin-top: 19px;margin-bottom: 5px;">Steps:</h3>

<ul><li style="list-style-type: disc;">Choose the All-Metal Hotend in the Slicer:

	<ul><li style="list-style-type: circle;">Select &quot;M5 All-Metal Hotend&quot; for slicing and printing during the slicing process.</li></ul>
	</li><li style="list-style-type: disc;">Update the Slicer:
	<ul><li style="list-style-type: circle;">Please update the Slicer to version V1.5.XX or above.</li><li style="list-style-type: circle;">If you are using version V0.9.XX or an earlier version, download the latest Slicer from<a href="https://www.ankermake.com/ankermake-studio?ref=naviMenu_2_1_img" style="text-decoration: none;" target="_blank"> AnkerMake Official Website</a>.</li></ul>
	</li></ul>

<img height="341" src="https://lh7-us.googleusercontent.com/docsz/AD_4nXcASCOh92atmHaBuzxzjkMecsP3Ze3dSwHHrj_zPsMTzFYTHDZmdAJtPl4D0NWeRvrg1n6E1tdwuFipTYq-PKfQmpvl7lfIiEIVOc_B3Xc3JJPzrxtTi0jxjaGOepJB8JPvwlrrrNNwCeUbJ705UyhDN3P0?key=CkkiGiwEiBRjhMUfKSOfFA" width="602"></img>


If you have any further questions, please reach out to us at support@ankermake.com.


</div>
